The intelligent communication cabinet supports RS485, Ethernet, and Wi-Fi connections for transmitting information from connected devices to the Isolarcloud software, which is accessible on both mobile phones and the website (https://www.isolarcloud.com.hk/).
- With a robust casing weighing 32 kg, it provides a sturdy solution for installing the Sungrow Com100A Data Logger.
- It supports various types of energy meters, weather monitoring devices, sensors, and other equipment. Maintenance of solar power plants is facilitated through remote web access for optimizing operational expenses (OPEX).
- With the convenient features of controlling reactive power and active power, adjusting grid power output no longer requires direct on-site operations, saving time and transportation costs. Direct monitoring on Isolarcloud or connecting directly to the logger through the Remote Maintenance mode makes O&M tasks simpler and more convenient.
- Password protection and data encryption ensure the security of the information. With an IP66 protection level and a wide operating temperature range, it can withstand direct environmental impacts, increasing safety and reliability.
- The Data Logger Sungrow COM100A supports remote operation and maintenance functions, including remote program updates and batch parameter settings for connected devices. The integrated software allows users to monitor intelligent current on each string, scan and diagnose online on the current and voltage curve (Online IV curve scan and diagnosis). With advanced system and diagnosis, it accurately identifies the location of abnormal PV positions.
Technical specifications:
| Model | COM100A |
| Communication | |
| Maximum number of devices | 200 |
| RS485 port | 4 |
| Ethernet | 2 * RJ45, 10 / 100 Mbps |
| Fiber optic switch (optional) | 2 fiber optic ports and 6 Ethernet ports |
| Fiber optic junction box (optional) | 4 Input & 24 Output |
| I/O module (optional) | 4-DI, 2-PT100, 2-AI (0 – 10V), 2-DO |
| PLC Communication | |
| Furthest communication distance | ≤ 1000m |
| Maximum no. of devices/channel | ≤ 30 inverters |
| Maximum communication delay time | ≤ 0.2 s |
| Rated voltage | 400 – 880 VAC |
| Maximum withstand voltage | ≤ 1000 VAC |
| Power supply | |
| Input AC | 100 ~ 277 VAC, 50 / 60 Hz |
| Power consumption | up to 60 W |
| Operating Conditions | |
| Operating Temperature | 30 oC ~ 60 oC |
| Storage Temperature | – 40 oC ~ 70 oC |
| Relative Humidity | 5% – 95% (Dew-free) |
| Operating Altitude | ≤ 4.000 m |
| Protection Level | IP66 |
| Mechanical specifications | |
| Dimensions (W x H x D) | 860 mm * 610 mm * 272 mm |
| Weight | 32 kg |
| Mounting method | Mount on wall or pole, indoor or outdoor |
| Cabinet material | Metal |
| Cable specifications | AC cable: 1 ~ 1.5 mm2 outdoor UV-resistant cable
PLC cable: 4 mm2 outdoor UV-resistant cable Fiber optic cable: Outdoor UV-resistant cable, outer diameter ≤18mm RS485 Cable: UV-resistant outdoor twisted pair cable (STP) 0.75 ~ 1.5 mm, outer diameter 6 ~ 18 mm. |
| Ordering Information | XB Solar – Authorized distributor for Sungrow products at the best prices in Vietnam |
| COM100A | COM100A includes Logger3000, AC adapter, PLC, SPD, MCCB, EDS (optional), OTB (optional), I/O module (optional) |
